TOMZN SPD DC 1000V 20KA~40KA Solar Surge Protector Device – TZG40-PV

Protect Your Solar Investment! Don't let lightning ruin your Inverter!

Protect your solar power system and sensitive electronic equipment from unpredictable voltage spikes and lightning surges.

The TOMZN TZG40-PV is a high-quality DC Surge Protective Device (SPD) specifically designed for photovoltaic (PV) systems operating at up to 1000V.

Key Features:

• High Surge Capacity: Designed to handle nominal discharge currents (In) of 20kA and maximum discharge currents (Imax) of up to 40kA.
• Rapid Response: Instantly diverts excess voltage to the ground, preventing damage to your solar inverter and home appliances.
• Safety Certified: Fully CE certified and manufactured by TOMZN, a trusted name in electrical protection.
• Visual Indicator: Features a clear status window (Green for OK, Red for Replace) so you can monitor the health of your protection at a glance.
• Easy Installation: Standard 35mm DIN rail mounting makes it compatible with most distribution boxes.
• Durable Build: Made with high-quality flame-retardant materials to ensure long-term reliability in harsh environments.

Technical Specifications:

• Model: TZG40-PV
• Pole: 2P
• Max Operating Voltage (Ucpv): 1000V DC
• Nominal Discharge Current (In): 20kA
• Max Discharge Current (Imax): 40kA
• Voltage Protection Level (Up): ≤ 3.2kV
• Mounting: 35mm DIN Rail

Package Includes:

• 1 x TOMZN DC 1000V 40KA Surge Protector Device
